Description

Positioning & Core Value

The EL series freeze dryers are positioned with " ultimate economy " as their core focus, tailored for users with limited budgets but requiring large-scale production. They utilize carbon steel, aluminum, stainless steel, and copper, paired with mature and stable domestic components. While strictly controlling costs, they ensure reliable operation, achieving an ultimate cost-performance advantage of "higher capacity for the same price, and lower cost for the same capacity." The products are widely applicable to various industries including food, health products, pet food, coffee, and dairy products, providing economical and practical freeze-dry solutions for medium-sized processing.

II. Core Advantages and Flexible Adaptive Design

Balancing Cost & Efficiency

Multiple feeding modes: Supports direct freeze-drying of pre-treated frozen materials, and can also be adapted to multi-path freezing solutions for fresh materials. By adding a refrigerator or quick-freezing machine with an independent refrigeration system, it can achieve parallel operation of "pre-batch freeze-drying + post-batch freezing", which greatly shortens the production interval and improves the overall capacity. The operation process is very simple.

Users only need to put the tray of pre-loaded materials into the equipment and start the automatic program to complete the freeze-drying.  Upgraded space utilization: The compact structural design integrates and optimizes the internal space of the chamber, maximizing the material loading capacity within a limited volume; at the same time, it reduces the power loss of the support system, achieving energy saving and consumption reduction, and significantly reducing electricity costs in the long term.Convenient loading, unloading and maintenance: The shelves and chambers are designed to be disassembled and equipped with dual guide rails. The shelf system can be moved out of the chamber as a whole, which not only facilitates the batch loading and unloading of materials, but also provides enough operating space for equipment maintenance and reduces downtime for repairs.

Global easy transport

Low-cost cross-border delivery: Small and medium-sized equipment can be directly loaded into 20-foot/40-foot standard containers, significantly reducing international transportation costs; the compact installation area adapts to the space constraints of various overseas factories, further saving on site rental costs. Globally compatible standards: It can be customized to adapt to local voltage and frequency standards according to the needs of different countries/regions, and can be put into use without additional modifications; the control panel has four mainstream languages built-in, breaking down language barriers and meeting the operating needs of international users.

Precise Control & Quality Service

Full-parameter safety monitoring

Real-time monitoring and precise control of core parameters such as pressure and temperature during the freeze-drying process, equipped with a complete system protection mechanism to effectively avoid abnormal risks such as over-temperature and over-pressure, and ensure production safety and stable product quality.

Intelligent management & control

Supports upgrading to industrial computers or mobile applications for remote monitoring functions, allowing users to keep track of production progress and equipment status in real time and achieve flexible operation and maintenance; the remote monitoring function is suitable for local large-scale production and also facilitates multinational companies to manage overseas production.

Hassle-free installation and support

Small and medium-sized models feature an integrated design, with all supporting systems pre-assembled and tested before leaving the factory; users can simply connect the power supply on-site for immediate use. Larger equipment requires only 3-5 days for installation and commissioning, significantly shortening the production cycle. A one-year warranty and lifetime free after-sales technical consultation are provided. Overseas users can enjoy full support including on-site installation guidance, equipment commissioning, and personnel training, completely eliminating after-sales concerns associated with cross-border procurement.

Applications and Core Value

The EL series is based on the core values of "economical and practical, flexible and adaptable, worry-free and reliable," precisely matching the cost control needs of startups, the large-scale production needs of small and medium-sized processing plants, and the cost-effective procurement needs of overseas users. Whether it's bulk freeze-drying for food processing plants, cost optimization for pet food companies, or low-asset investment for cross-border entrepreneurs, the EL series can achieve breakthroughs in freeze-drying capacity while strictly controlling budgets, thanks to its advantages of "low cost, high efficiency, and strong adaptability," making it the ideal choice.
EL Series Technical Parameter

EL Series Technical Parameter

Model EL-500 EL-750 EL-1000 EL-1500 EL-2000
Capacity 500kg 750kg 1000kg 1500kg 2000kg
Condenser -45°C -45°C -45°C -45°C -45°C
Shelf(°C) 5 to 80 5 to 80 5 to 80 5 to 80 5 to 80
Product(°C) Pre-frozen Pre-frozen Pre-frozen Pre-frozen Pre-frozen
Shelf(m²) 50 m² 75 m² 100m² 150m² 200m²
Compressor included included included included included
Refrigerant R22 R22 R22 R22 R22
Cooling Air/water Air/water Air/water Air/water Air/water
Vacuum included included included included included
Pressure 10 Pa 10 Pa 10 Pa 10 Pa 10 Pa
Defrost by hot water by hot air by hot water by hot water by hot water
Power 83kw 112kw 164kw 243kw 305kw
Control PLC+HMI PLC+HMI PLC+HMI PLC+HMI PLC+HMI
Installation 50 m² 100 m² 150 m² 200 m² 300 m²
Dimension (m) 5.0×2.1×2.5 6.2×2.1×2.5 7.2×2.4×2.8 9.0×2.4×2.8 11.2×2.5×3.0
Weight (kg) 6000 8000 10000 13000 15000
Model EL-500 EL-750 EL-1000 EL-1500 EL-2000
Capacity500kg750kg1000kg1500kg2000kg
Condenser-45°C-45°C-45°C-45°C-45°C
Shelf(°C)5 to 805 to 805 to 805 to 805 to 80
Product(°C)Pre-frozenPre-frozenPre-frozenPre-frozenPre-frozen
Shelf(m²)50m²75m²100m²150m²200m²
Compressorincludedincludedincludedincludedincluded
RefrigerantR22R22R22R22R22
CoolingAir/waterAir/waterAir/waterAir/waterAir/water
Vacuumincludedincludedincludedincludedincluded
Pressure10 Pa10 Pa10 Pa10 Pa10 Pa
Defrostby hot waterby hot airby hot waterby hot waterby hot water
Power83kw112kw164kw243kw305kw
ControlPLC+HMIPLC+HMIPLC+HMIPLC+HMIPLC+HMI
Installation50m²100m²150m²200m²300m²
Dimension (m)5.0×2.1×2.56.2×2.1×2.57.2×2.4×2.89.0×2.4×2.811.2×2.5×3.0
Weight (kg)60008000100001300015000
